Q235nh Steel Plate
Q235nh Steel Plate
Q235nh Steel Plate
01 / 04

Q235nh Steel Plate

Product Details

Q235nh Steel Plate

Q235NH atmospheric corrosion resistance steel plate is widely used in containers, chimney, railway engineering and other outdoor steel such as a large outdoor sculpture steel, Lasers produce a high intensity light source the size of a pin head. Q235NH atmospheric corrosion resistance steel plate also is known as hot strip rolling Cowden steel, corrosion-resistant steel.

The energy produced by this light source vaporizes metal. Controlled by CNC (Computerized Numerical Controls) this very narrow beam of high energy light can be directed and its movement controlled with pin point accuracy.

Q235nh Steel Plate Specification

Steel Grade

NM360, NM400, NM450, NM500, NM550, NM600,XAR400,AR450 AR500 ,ect

Standard

GB, ASTM, JIS ,DIN, ASTM

Thickness

2mm-300mm

Width

500-2500mm

Length

1000mm-12000mm or according to customer's special request

Tolerance

Thickness: +/-0.02mm, Width:+/-2mm

1MOQ

1Tons



Application

1.Automobile, Bridges, Buildings.
2.Machinery, Pressure vessel industries.
3.Ship building, Engineering construction.
4.Mechanical manufacturing, Pavement slab, ect.

Package

Bundle with steel strip,Container shipping

Capacity

200000 tons /month

Mill MTC

can be supplied before shipment

Inspection

The Third Party inspection can be accepted,SGS,BV

Q235nh Steel Plate chemical composition

Grade C Si Mn P S Cu Cr Ni
Q235NH ≤0.13' 0.10-0.40 0.20-0.60 0.03 ≤0.030 0.25-0.55 0.4-0.8 ≤0.65

Q235nh Steel Plate Physical Properties

Grade

Yield strength

Tensile strength

Elongation min %

GB/T 4171 Q235NH

215-235 Mpa

360-510 Mpa

23
