Spa-h Weathering Steel Plate
Spa-h Weathering Steel Plate
01 / 03

Spa-h Weathering Steel Plate

Product Details

Spa-h Weathering Steel Plate

JIS G3125 SPA-H Corten steel,SPA-H steel plate/Sheet. SPA-H low alloy high strength atmospheric corrosion resisting steel.
Key words:SPA-H, JIS G3125 SPA-H hot rolled steel, JIS G3125 SPA-H steel plate/sheet/bar/section steel. JIS G3125 SPA-H Corten steel, SPA-H Weathering steel, SPA-H Weathering resistant steel, SPA-H atmosphere corrosion resistance steel.
JIS G3125 SPA-H Corten steel widely used in air preheater, economizer, railway carriage, containers production, bridge building , construction and so on.

Spa-h Weathering Steel Plate Specification

item

value

Place of Origin

China

Shandong

Brand Name

Zhangpu

Application

Container Plate

Type

Steel Coil

Thickness

0.8-1.2mm

Standard

ASTM

Width

1000-2200mm

Length

as your request

Certificate

JIS, ISO9001

Grade

SS400,Q235,Q345R,SA302,SA516,A572,S275,S355

Tolerance

±1%

Processing Service

Bending, Welding, Decoiling, Cutting, Punching

Skin Pass

Yes

Alloy Or Not

Non-Alloy

Delivery Time

within 7 days

Product Name

Hot Rolled Steel Coil Plate Iron Sheet Steel From China High Quality

Material

ASTM/AISI/SGCC/CGCC/TDC51DZM/TDC52DTS350GD/TS550GD/DX51D+Z Q195-q345

Shape

Plate. Coil

Surface

Black

Technology

Hot Rolledd

Payment term

L/C T/T (30% Deposit)

MOQ

1 Ton

Usage

Construction Structure

Package

Standard Seaworth Packing

PRICE TERM

CIF CFR FOB EX-WORK

Spa-h Weathering Steel Plate chemical composition

JIS G3125 SPA-H SPA-C Steel Chemical Composition:

C

Si

Mn

P

S

Cu

Cr

Ni

0.12

0.20-0.75

0.60

0.070-0.150

0.035

0.25-0.55

0.30-1.25

0.65

Spa-h Weathering Steel Plate physical properties

SPA-H SPA-C Steel Coil / Plate Mechanical Properties:

Grade

Thickness

Yield Strength

Tensile Strength

Elongation

SPA-H

t≦6mm

≧355 Mpa

≧490 Mpa

≧22%

SPA-H

6<t≦16mm

≧355 Mpa

≧490 Mpa

≧15%

SPA-C

0.6<t≦2.3mm

≧315 Mpa

≧450 Mpa

≧26%

Spa-h Weathering Steel Plate equivalent steel grade

Standard

Corten Steel, Weathering Steel, Atmosphere Corrosion Resistant Steel Grades

CORTEN

Corten A

Corten B

ASTM A588/A588M

A588 Grade A

A588 Grade B

A588 Grade C

A588 Grade K

ASTM A242/A242M

A242

ASTM A606/A606M

A606 Type 2

A606 Type 4

A606 Type 5

ASTM A709/A709M
(≤100mm)

A709 Gr 36

A709 Gr 50

A709 Gr 50S

A709 Gr 50W

A709 Gr HPS50W

A709 Gr HPS70W

A709 Gr 100

A709 Gr 100W

A709 Gr HPS100W

ASTM A871/A871M

A871 Grade 60

A871 Grade 65

EN 10025-5
(≤150mm)

S235J0W

S235J2W

S355J0WP

S355J2WP

S355J0W

S355J2W

S355K2W

TB/T 1979
(≤20mm)

Q295NQR2

Q295NQR3

Q345NQR2

Q345NQR3

Q345NQR4

Q350EWR1

Q400NQR1

Q450NQR1

Q450EWR1

Q500NQR1

Q550NQR1

Q265NQL2

Q310NQL2

Q310NQL3

GB/T 4171
(≤100mm)

Q295GNH

Q355GNH

Q265GNH

Q235NH

Q310GNH

Q295NH

Q355NH

Q415NH

Q460NH

Q500NH

Q550NH

JIS G 3114
(≤200mm)

SMA400AW

SMA400BW

SMA400CW

SMA400AP

SMA400BP

SMA400CP

SMA490AW

SMA490BW

SMA490CW

SMA490AP

SMA490BP

SMA490CP

SMA570W

SMA570P

JIS G3125 (≤16mm)

SPA-H

SPA-C

Other Grades

WR50A

WR50B

B480GNQR
